Description
3″ Garage Door Pulley With Strap
3″ Garage Door Sheave
Includes: Clevis Pulley w/ Fork, 3/8 Bolt, Nut & Lock Washer
Clevis Pulley attaches to the ends of the extension spring of extension spring garage doors
We stock this pulley with out the fork here – GARAGE DOOR PULLEY
Rated at 100 Pounds @ 10K Cycles of a 8′ Tall Overhead Garage Door
3/8″ Bore
1/2″ Wide
3″ Across
Ball bearings
6 – pressed rivets holding the pulley together
Accepts up to 1/4″ cable but we use this pulley for up to 3/16: max diameter cable.
We also stock other pulleys including another cast iron pulley – CLICK HERE
We stock cable in any length up to 500′ in:
1/16″, 3/32″, 1/8″, 5/32″, 3/16″ & 1/4″
Center race holds 9 ball bearings that are pre lubricated but do need periodic lubrication.
This is a heavy duty pulley wheel that can be used for any number of uses. For use on garage doors it can be used as a fixed stud pulley or by adding a pulley strap, used as a clevis pulley.
Commonly referred to as a Pulley and or a Sheave this is an item that has been around a very long time and as stated has near unlimited uses and potential. If you need a heavy duty pulley this may be just what you need. These are good to have on hand, great for rigging up material lifts using with rope for many different uses but typically used with cable.
Garage Door Clevis Pulley – 3″
3″ Garage Door Pulley With Strap
